android蓝牙开发

MrLee2015-4-28 2441

090522_bluetooth


检查设备是否支持蓝牙实现步骤:
判断是否有蓝牙设备。是否开启蓝牙。若没有开启则请求开启蓝牙。操作需要权限 :
BluetoothAdapter ba = BluetoothAdapter.getDefaultAdapter();
    if(null!=ba){
        System.out.println("本机有蓝牙设备");

        if(!ba.isEnabled()){
            Intent intent=new Intent(BluetoothAdapter.ACTION_REQUEST_ENABLE);
            startActivity(intent);  //或者ba.enable();  //同样的关闭WIFi为ba.disable();
    }else{
         System.out.println("本机没有蓝牙设备");
    }
设置蓝牙的可见时间(允许其他设备搜索到)实现步骤:设置蓝牙的可见时间需要权限:
Intent intentvisible=new Intent(BluetoothAdapter.ACTION_REQUEST_DISCOVERABLE);

intentvisible.putExtra(BluetoothAdapter.EXTRA_DISCOVERABLE_DURATION, 400);
//这个值么默认120秒,超过300秒将会被设置为300.可是在我的设备上是2400也行。API出错?
this.startActivity(intentvisible);
获取扫描到的设备实现步骤:调用开始扫描的代码需要权限:消耗12秒的时间,当扫描到广播后,会发送广播消息,注册一个广播来接收注册一个扫描完毕的广播,在这个广播中关闭扫描到蓝牙通知的广播,并且关闭自己
//开始扫描
BluetoothAdapter ba = BluetoothAdapter.getDefaultAdapter();
ba.startDiscovery();
//注册这个扫描广播
IntentFilter intentfilter=new IntentFilter(BluetoothDevice.ACTION_FOUND);
       MyReceiver mr=new MyReceiver();
       this.registerReceiver(mr, intentfilter);

//注册一个扫描完毕的广播
class FinishFound extends BroadcastReceiver
   {

    @Override
    public void onReceive(Context context, Intent intent) {
        BluetoothActivity.this.unregisterReceiver(this);
        BluetoothActivity.this.unregisterReceiver(mr);
    }

   }
获取已经配对的蓝牙设备(集合)实现步骤:获取集合。需要权限:
Set device=ba.getBondedDevices();
     if(device.size()>0)
    {
       for(BluetoothDevice bd:device)
        {
            System.out.println(bd.getAddress()+bd.getName());
        }
    }
蓝牙发送数据(发送字符串)实现步骤:
发送字符串到一个配对的设备。需要已知名和地址。
private void sendDataToPairedDevice(String message ,BluetoothDevice device){
           byte[] toSend = message.getBytes();
            try {
                UUID applicationUUID = UUID.fromString("8ce255c0-200a-11e0-ac64-0800200c9a66");
                BluetoothSocket socket = device.createInsecureRfcommSocketToServiceRecord(applicationUUID);
                OutputStream mmOutStream = socket.getOutputStream();
                mmOutStream.write(toSend);
                // Your Data is sent to  BT connected paired device ENJOY.
            } catch (IOException e) {
                Log.e(TAG, "Exception during write", e);
            }
        }
调用以上的方法:
sendDataToPairedDevice("text to send" ,bluetoothDevice);
蓝牙接收数据实现步骤:
启动一个service去监听是否有数据返回。一旦有数据返回就启动一个线程去处理数据处理完数据,通过广播去通知UI。服务类
/**
 *负责监听启动应用程序 后的接收数据
 */
public class ReceiveThread extends Service {

    private Socket socket;
    private String workStatus;  // 当前工作状况,null表示正在处理 | success表示处理成功,failure表示处理失败
    public static Boolean mainThreadFlag = true;  //状态
    @Override
    public IBinder onBind(Intent intent) {
        // TODO Auto-generated method stub
        return null;
    }
    private void doListen()
    {
        Log.d("chl", "doListen()");
        //开始监听
        while (mainThreadFlag)
        {
         //开始监听数据
          new Thread(new ThreadReadWriterSocketServer(ReceiveThread.this, socket));
        }
    }
}
线程工作类
public class ThreadReadWriterSocketServer implements Runnable{
    private  Socket client=null;
    private Context context=null;
    public ThreadReadWriterSocketServer(Context context,Socket client)
    {
        this.context=context;
        this.client=client;
    }


    @Override
    public void run()
    {
        Receive();
    }


    private void Receive() {
    //处理数据
    }
}
十六进制转换蓝牙通信需要通常转换十六进制进行,方法如下
 public static String bytesToHexString(byte[] bytes) {
        String result = "";
        for (int i = 0; i < bytes.length; i++) {
            String hexString = Integer.toHexString(bytes[i] & 0xFF);
            if (hexString.length() == 1) {
                hexString = '0' + hexString;
            }
            result += hexString.toUpperCase();
        }
        return result;
    }
